FROM DIGITAL SCAFFOLD MODELS
TO INTERACTIVE FIELD VISUALIZATION

The SIM2Field XR App brings Layher’s digital scaffold models directly to the construction site to support work preparation, scaffold assembly, and inspection. Project data from LayPLAN CAD can be transferred to the app by link or QR code, giving field teams access to 3D scaffold models and associated project information on a mobile device.

Project data can include supporting documents such as PDFs and photos and can be made available offline for use in the field. When an internet connection is available, updated project information can be synchronized after changes are made.

SIM2Field XR App
Layher Software

ONE CONNECTED DIGITAL WORKFLOW

Digital Planning Connected Directly to Field Visualization and Assembly

The SIM2Field XR App extends Layher’s connected digital workflow by bringing LayPLAN CAD project data and 3D scaffold models directly to the construction site. Field teams can access project information, view scaffold geometry, identify components, and use augmented reality to visualize the planned scaffold within the real environment.

01.

EXISTING CONDITIONS

Identify the structure and current site conditions

02.

3D LASER SCAN

Capture existing conditions with millimeter accuracy

03.

DIGITAL TWIN

Create an accurate digital representation of the site

04.

LAYPLAN PLANNING & MATERIAL OPTIMIZATION

Plan the scaffold and optimize material requirements

05.

DIGITAL DESIGN & ENGINEERING

Develop and coordinate the scaffold design

06.

LOGISTICS & MATERIAL COORDINATION

Coordinate materials and project logistics

07.

SIM2FIELD &
SIM2FIELD XR APP

Bring digital scaffold models and project information to the field to support visualization and assembly

08.

FIELD ASSEMBLY

Support accurate and efficient scaffold assembly

09.

COMPLETED SCAFFOLD PROJECT

Complete the project through one coordinated workflow

By connecting digital planning with interactive 3D visualization and augmented reality, the SIM2Field XR App helps project teams carry coordinated scaffold information from planning into field execution. This supports clearer communication, improved project understanding, and more efficient scaffold assembly using the same digital model developed during planning.

WHY USE THE SIM2FIELD XR APP?

The SIM2Field XR App brings Layher’s 3D scaffold models and project information directly to the construction site. By combining interactive model access, project documentation, component information, and augmented reality, the app helps field teams better understand planned scaffold structures and supports work preparation, assembly, inspection, and coordination.

  • Access 3D scaffold models directly on a mobile device
  • Transfer project data from LayPLAN CAD by link or QR code
  • Reduce reliance on 2D paper assembly plans
  • View project documents including PDFs and photos
  • Access project data offline in the field
  • Identify scaffold components and view associated component information
  • Use intelligent and interactive parts list functions
  • Visualize selected scaffold areas using the cutting / Limit Box function
  • Use explosion mode to view assembly details
  • Place the virtual scaffold in the real environment using augmented reality
SIM2Field XR App

IDEAL APPLICATIONS

The SIM2Field XR App can support projects where teams benefit from viewing and understanding complex scaffold structures directly in the field. By bringing 3D scaffold models, project documents, component information, and augmented reality visualization to a mobile device, the app supports work preparation, assembly, inspection, and coordination across a wide range of scaffold projects.

Potential applications include:

  • Industrial facilities and processing plants
  • Refineries and petrochemical sites
  • Power generation facilities
  • Commercial and infrastructure projects
  • Shipbuilding, shipyards, and marine projects
  • Complex scaffold structures and access solutions
  • Projects where advance visualization can improve coordination
  • Sites where teams need digital model and project information directly in the field

KEY XR APP CAPABILITIES

Interactive 3D Model Access for Field Assembly and Coordination

The SIM2Field XR App gives project teams direct access to 3D scaffold models and project information on a mobile device. The app combines model visualization, component data, interactive parts lists, cutting functions, explosion views, and augmented reality to support work preparation, scaffold assembly, inspection, and field coordination.

Key capabilities include:

  • View LayPLAN CAD scaffold models on a mobile device
  • Access component designation, article number, and weight
  • Display the complete material list for the scaffold structure
  • Highlight, show, or hide selected scaffold components
  • Use explosion mode to examine assembly details
  • Use the cutting / Limit Box function to visualize selected scaffold areas
  • Place and align the virtual scaffold in the real environment using augmented reality
SIM2Field XR App
AUGMENTED REALITY VISUALIZATION

AUGMENTED REALITY VISUALIZATION

Place the Digital Scaffold in the Real Environment

The SIM2Field XR App allows 3D scaffold models to be placed directly within the real construction environment using augmented reality, giving teams a clear visual reference before and during assembly.

In Construction Mode, the set-down point can be defined and the model aligned using touch gestures. The pivot point can also be set, and the model locked to help prevent unintended movement.

Key Benefits

  • Visualize the planned scaffold directly in the real environment
  • Support advance coordination before scaffold assembly
  • Align and position the digital model using touch controls
  • Define set-down and pivot points within the model
  • Lock the model in position to help prevent unintended movement
  • Use the cutting / Limit Box function to visualize selected scaffold areas

PROJECT REQUIREMENTS

Device and Project Requirements for SIM2Field XR App

The SIM2Field XR App uses project data directly from LayPLAN CAD and is designed for use on supported tablets and Windows devices. Project information can be transferred by link or QR code and made available on the device for field use.

Requirements include:

  • iPad with iPadOS 12.0 or later
  • Recommended: iPad Pro 5th Generation or newer
  • Android tablet with Android 12 or newer
  • Windows 11
  • Augmented Reality mode is not available in the Windows version
  • Transfer project data from LayPLAN CAD by link or QR code

Why It Matters
Meeting these requirements gives field teams access to the 3D scaffold model, project documents, component information, and XR functions needed to support work preparation, assembly, inspection, and field coordination.

SIM2Field XR App

FREQUENTLY ASKED QUESTIONS ABOUT SIM2FIELD XR APP

The SIM2Field XR App is a digital field tool designed to support work preparation, scaffold assembly, inspection, and coordination on the construction site. It gives field teams access to 3D scaffold models and associated project information on supported mobile devices.

The app allows crews to use 3D scaffold models directly in the field as a visual reference during assembly. Interactive model views, component information, parts lists, explosion mode, and augmented reality help teams better understand the planned scaffold structure.

Project data is transferred directly from LayPLAN CAD by link or QR code. Projects can also include associated documents such as PDF files and photos.

Yes. Project data can be downloaded to the mobile device and made available offline for field use. When an internet connection is available, updated project information can be synchronized after changes are made.

In addition to scaffold geometry, users can view information about Layher scaffold components, including article designation, article number, and component weight. The complete material list for the scaffold structure can also be displayed.

Augmented Reality mode allows the virtual scaffold model to be placed within the real construction environment. The model can be positioned, aligned using touch gestures, and locked in place to help teams visualize the planned scaffold in relation to actual site conditions.

The cutting / Limit Box function, function allows users to focus on selected portions of the scaffold model. In Augmented Reality mode, this helps teams visualize specific areas of the scaffold structure more clearly.

The app supports iPads with iPadOS 12.0 or later, Android tablets with Android 12 or newer, and Windows 11 devices. An iPad Pro 5th Generation or newer is recommended.

READY TO BRING
DIGITAL SCAFFOLD MODELS INTO THE FIELD?

Connect with Layher to learn how the SIM2Field XR App can improve field visualization, scaffold assembly, project coordination, and access to digital scaffold information on the jobsite.
