ALLROUND BRIDGING SYSTEM
Layher Commercial & Industrial
Allround Bridging System
THE ALLROUND BRIDGING SYSTEM IS THE IDEAL ADDITION TO LAYHER ALLROUND SCAFFOLDING
From general scaffolding applications to the pedestrian application, the Layher Allround® Bridging system offers key advantages and is fully compatible with Layher Allround® Scaffolding. Typical installations range from foot bridges to support girders for heavy loads, with a choice of bay sizes to optimize versatility.
Construction can be done directly on the scaffold or at ground level for craning into position, Optional add-on include steel decks, Layher ‘Protect’ panels, child-proof guardrails and temporary roof sections. As a result, clear benefits almost independent of terrain and pedestrian traffic requirements can be readily achieved.
When used as a support girder, installations such as scaffold foundation, roof structures and even suspended scaffolding can be installed, significantly enhancing the versatility of the bridging design.
ALLROUND BRIDGING SYSTEM OVERVIEW
The Layher Allround Bridging System provides a versatile solution for creating pedestrian access, bridging structures, and support applications within scaffolding systems. Fully compatible with Layher Allround Scaffolding, the system enables safe and efficient bridging across obstacles, openings, and varying site conditions.
Designed for flexibility and performance, the system can be installed directly within scaffold structures or configured as an independent bridging solution. Its modular design supports a wide range of applications, including access platforms, suspended walkways, and support structures.
The use of standardized components allows for efficient assembly, reliable load transfer, and consistent performance across construction and industrial environments.
ALLROUND BRIDGING SYSTEM FUNCTION
The Layher Allround Bridging System is designed to create stable bridging structures within scaffolding systems, enabling safe access and load-bearing support across spans and obstacles.
Using modular components, the system can be configured to provide:
- Pedestrian access bridges within scaffold structures
- Bridging over openings, roadways, or restricted areas
- Support structures for temporary or permanent applications
- Integration with scaffold decks, guardrails, and roofing systems
The system integrates seamlessly with Layher Allround Scaffolding, allowing efficient installation, structural stability, and adaptability to project-specific requirements.
System Advantages
Rapid Assembly
Bolt-free pin and wedge head connections enable fast and efficient installation.
Efficient Installation Process
Pre-assembly at ground level and positioning by crane support streamlined erection on site.
Enhanced Safety Integration
Compatible with Layher Protect System components for cladding and roofing, improving pedestrian safety.
System Compatibility
Can be assembled using all Layher system decks, depending on load requirements.
Flexible Span Configuration
Standard lengths of 2.07 m (6 ft 9 in) and 2.57 m (8 ft 5 in) allow adaptable bridging layouts.
Large Span Capability
Bridging spans of up to approximately 22 m (72 ft) can be achieved, depending on configuration.
Structural Versatility
Supports the strengthening of scaffolding structures, working platforms, and temporary roofing systems.
Applications
The Allround Bridging System is used across construction, industrial, and infrastructure projects where safe access and bridging over obstacles are required.
Applications include:
- Pedestrian access bridges within scaffolding structures
- Bridging over roadways, excavations, and restricted areas
- Temporary walkways and access platforms
- Support structures for scaffolding and roofing systems
- Industrial and infrastructure access solutions
LAYHER ALLROUND BRIDGING SYSTEM
Layher’s Allround Bridging System is in use as a pedestrian bridge over State Highway L 1036, connecting both parts of the 2016 State Horticultural Show in Oehringen.
